科技论文和展示

这里您可以找到在全球 COMSOL 年会上所有用户报告的演示文稿。这些演示文稿介绍 COMSOL 用户是如何使用 COMSOL Multiphysics 进行创新性研究和产品设计。研究主题涵盖了包括电气、机械、流体和化工等范围广泛的行业和应用领域。请使用“快速搜索”来查找与您的研究领域相关的演示文稿。

Numerical Study of Navier-Stokes Equations in Supersonic Flow over a Double Wedge Airfoil using Adaptive Grids

V. Gopal[1], R. Kolluru[1]
[1]BMS College of Engineering, Bangalore, Karnataka, India.

Numerical study of aerodynamic characteristics in steady laminar supersonic flow over a double wedge airfoil is carried out using commercially available finite element based CFD tool COMSOL Multiphysics. The aerodynamic characteristics of double wedge airfoil like lift and drag are analyzed by solving Navier-Stokes equations in the flow field for various thickness to chord ratios (t_c) and angle ...

Optical and Electrical Modeling of Three Dimensional Dye Sensitized Solar Cells

P. Guo[1]
[1]Northwestern University, Evanston, IL, USA

Dye sensitized solar cells (DSSCs) have received tremendous attention as alternative photon harvesting devices. While the sintered TiO2 nanoparticle network attached with dye molecules achieves efficient photon absorption, the electrons have to diffuse through the long TiO2 network to reach the contact, resulting in a high electron density and thus increased recombination. Extensive research ...

Modeling Residual Stresses in Arc Welding

F. Roger[1], and A. Traidia[2]
[1]ENSTA Paristech, Paris, France
[2]AREVA NP, Saint Marcel, France

The prediction of mechanical response of assemblies during arc welding necessitates the knowledge of thermal history of the components and the constitutive behavior of the materials. COMSOL can simulate thermal and structural interaction but it needs to evaluate the time evolution of internal variables like viscoplastic strain and hardening parameters. In the present paper we extend the ...

Numerical Computation of Two-Phase Flow in Porous Media

D. Droste[1], F. Lindner[1], C. Mundt[1], M. Pfitzner[1]
[1]Universität der Bundeswehr, Munich, Bavaria, Germany

In this study we investigate the heat and mass transfer in a porous media with phase change. The liquid fluid is injected from one side and heated from the other side, where it leaves the porous material in a gaseous state. Dominant forces are capillary interactions and two-phase heat conduction. To model the process we use a two-phase mixture model on a macroscopic scale. This model is ...

Lamb Waves and Dispersion Curves in Plates and It’s Applications in NDE Experiences Using Comsol Multiphysics

P. Gómez, J. P. Fernandez, and P. D. García
Hydro-Geophysics & NDE Modeling Unit
University of Oviedo
Mieres, Spain

In this paper, a model for numerically obtaining lamb wave modes and dispersion curves in plates is presented. It is shown that COMSOL Multiphysics can be employed to simulate the behavior of guided waves in dispersive plates, which is useful for NDE applications. A two dimensional steel plate (4x0.1 meters) is excited with a space-time impact point source. To model the point source, we use ...

Design of a MEMS Capacitive Comb-drive Accelerometer

T. Kaya[1], B. Shiari[2], K. Petsch[1], and D. Yates[2]
[1]Central Michigan University, School of Engineering and Technology, Mount Pleasant, MI
[2]University of Michigan, Dept. of Electrical Engineering and Computer Science, Ann Arbor, MI

In this work, a MEMS low-g accelerometer with three sensitive directions is designed for health monitoring applications. The accelerometer may have different sensitivity in different axes. The proof-mass of the device is suspended by four serpentine springs, and the comb drive structure is used to form the differential capacitor to measure the displacement of the proof-mass. The structure has an ...

Simulation of Cyclic Voltammetry of Ferrocyanide/Ferricyanide Redox Reaction in the EQCM Sensor

H. Kwon, and E. Akyiano
Dept. of Engineering and Computer Science
Andrews University
Berrien Springs, MI

In this paper, the cyclic voltammetry behavior of Ferrocyanide/Ferricyanide, which is commonly used for electrochemical DNA detection experiment, was studied in the commercial EQCM-D setup (Q-sense) using the COMSOL Multiphysics. The model was established in a 3D geometry of QCM liquid cell. The simulation shows depletion of concentration of ferrocyanice following applied electrode potential. ...

Modeling of Two-Phase Flows

K. O. Lund
Engineering Consultant to SML Associates, Del Mar, CA, USA

Viscous equations are developed for regions with two interacting flowing fluids, or two fluid phases, such as occur in fluidized particle beds or the mixing of fluids. The descriptive equations are rendered into the standard COMSOL PDE matrix form, and solved over typical two-dimensional regions, as time-dependent interacting laminar flows.The model geometry selected is that of a so-called ...

Comparison of Darcy's Law, the Brinkman Equation, the Modified Navier-Stokes Equation and the Pure Diffusion Equation in PEM Fuel Cell Modeling

Z. Shi and X. Wang
Oakland University, Rochester, MI, USA

A two dimensional isothermal single phase PEM fuel cell model is developed and implemented in COMSOL Multiphysics, where Darcy's law, the Brinkman equation, the modified Navier-Stokes equation, and the pure diffusion equation are applied separately in porous electrodes. Three values of GDL permeability are investigated. Additionally, the order of the magnitude of each term in the modified N-S ...

Implementation of the Perfectly Matched Layer to Determine the Quality Factor of Axisymmetric Resonators in COMSOL

M.I. Cheema, and A.G. Kirk
McGill University, Montreal, QC, Canada

Due to the inseparability of the wave equation, numerical methods are needed to develop an accurate electromagnetic model for various axisymmetric resonators such as micro-discs and micro-toroids. Our purpose is the implementation of a perfectly matched layer to determine the quality factor of axisymmetric resonators with high accuracy in COMSOL. We treated the perfectly matched layer as an ...
