科技论文和展示

这里您可以找到在全球 COMSOL 年会上所有用户报告的演示文稿。这些演示文稿介绍 COMSOL 用户是如何使用 COMSOL Multiphysics 进行创新性研究和产品设计。研究主题涵盖了包括电气、机械、流体和化工等范围广泛的行业和应用领域。请使用“快速搜索”来查找与您的研究领域相关的演示文稿。

Nondestructive Testing of Composites Using Model Based Design

E. Nesvijski[1]
[1]ACOUSTICS@MBD CONSULTANTS, LLC, Westborough, MA, USA

There is a practical interest among composite materials manufacturers to high-speed accurate non-destructive evaluation (NDE) technology for voids inspection when these voids are natural components of such complex structures like resin insulated layer of double-sided copper-clad laminates. Model based design (MBD) of NDE system is one of principal solutions for voids inspection in such composites ...

Laser-Ultrasonics Wave Generation and Propagation FE Model in Metallic Materials

A. Cavuto[1], G.M. Revel [1], M. Martarelli [2], F. Sopranzetti [2]
[1]Università Politecnica delle Marche, Ancona, Italy
[2]Università e-Campus, Novedrate (CO), Italy

A 2D axisymmetric model was considered in order to evaluate the propagation paths of the ultrasonic waves generated inside an aluminum plate sample due to a rapid thermal expansion produced by laser pulse. Laser Doppler Vibrometer is used to experimentally validate the numerical results of the wave propagation in the material. The presented numerical model is able to identify directivity patterns ...

Analyzing Muffler Performance Using the Transfer Matrix Method

K. Andersen
Dinex Emission Technology A/S, Middelfart, Denmark

Exhaust noise must meet legislation targets, customer expectations and cost reduction which call for design optimization of the exhaust systems in the design phase. One solution is to use 3 dimensional linear pressure acoustics and calculate the transfer matrix of the muffler. The transfer matrix is the basis for calculating either the insertion loss or transmission loss of a muffler. The 3D ...

Investigation on Sensor Fault Effects of Piezoelectric Transducers on Wave Propagation and Impedance Measurements

I. Buethe[1], C.-P. Fritzen[1]
[1]University of Siegen, Institute of Mechanics and Control Engineering-Mechatronics, Siegen, Germany

For active Structural Health Monitoring (SHM), one popular sensor type is the piezoelectric wafer active sensor (PWAS) due to its multi-purpose application as actuator and sensor and its low cost. It is used to generate a wave field, which interacts with the structure and is recorded by a second set of PWASs. This method is called acousto ultrasonics. The change in wave field from transducer ...

Acoustic Field Comparison of High Intensity Focused Ultrasound Using Experimental Characterization and Finite Element Simulation

J. L. Teja[1], A. Vera[1], L. Leija[1]
[1]Department of Electrical Engineering, Cinvestav-IPN, Mexico D.F., Mexico

High Intensity Focused Ultrasound (HIFU) is used as a noninvasive technique of tissue heating and ablation for different medical treatments. This paper presents a quantitative comparison of HIFU acoustic fields experimentally obtained versus simulated acoustic fields. Acoustic field characterization was realized in two HIFU transducers using water as a propagation medium. Also, simulations were ...

Ultrasonic Beam Steering in Isotropic Media

S. Jeyaraman, B. Ganesan, and M. Kumar
GE Global Research, Bangalore

In this paper, a numerical model for time-domain ultrasound plane wave propagation for a desired angle is presented. The propagating angle is a function of the distance and the time-delay between the individual elements, and the propagating sound speed. In this model, the control parameter 'time' is used for steering the beam at the desired angle. We present an application of the proposed ...

Modeling and Testing of Carbon-Fiber Doubly-Resonant Underwater Acoustic Transducer

A. Morozov[1]
[1]Teledyne Technologies Inc., Falmouth, MA, USA

This paper describes the COMSOL Multiphysics® simulation and the test of a low-frequency (500Hz) sound source for long-range acoustic communications. This design uses innovative carbon-fiber composite materials.To meet the demand for the frequency range the doubly resonant organ pipe resonator was suggested. A multi-resonant system usually needs a precise, complicated adjustment of its ...

Scale-up Design of Ultrasound Irradiator for Advanced Oxidation Process (AOP) Using COMSOL Multiphysics® Simulation

Z. Wei[1]
[1]The Ohio State University, Columbus, OH, USA

Ultrasound is a promising green technology for the advanced oxidation process (AOP) since it adds no chemicals to the treated water. In this paper, COMSOL Multiphysics® was used as a tool to design and characterize an ultrasound irradiator with multi-stepped configuration, which aims to overcome disadvantages of typical irradiators and to enhance contaminant removal in large-scale water ...

SAW Sensors for Surgical Arm using Piezoelectric Devices

Rakesh Kumar Pati [1], SK Mohammed ali[1], Sakuntala Mahapatra[1], Millee Panigrahi[1]
[1]MEMS Design Centre, Dept. of ETC, Trident Academy of Technology, Bhubaneswar, Odisha, India

Despite of the existing successful clinical applications, however, the interaction, i.e. artificial sensing, between the robot and the patient is still very limited. With the help of various cameras, vision is almost the only feeling that a robot can have. In order to imitate the human skin, various signals e.g., the strength of pressure, change of strength, speed and acceleration should be ...

Development of a Reactive Silencer for Turbo Compressors

J. Smeulers[1], N. Gonzalez Diez[1]
[1]TNO, Delft, The Netherlands

Turbo compressors can generate high frequency tonal noise, causing nuisance in the environment. As the noise is radiated from the piping, a silencer is installed between the compressor and the pipe system. Commonly an absorption silencer is applied, which is a vessel that contains acoustic absorption material. Due to high flow velocities and vibrations the absorption material may be blown out of ...
