Flow Past a Cylinder

The following model examines unsteady, incompressible flow past a long cylinder placed in a channel at right angle to the oncoming fluid. The cylinder is offset somewhat from the center of the flow to make the steady-state symmetrical flow unstable. The simulation time necessary for a periodic flow pattern to appear is difficult to predict. A key predictor is the Reynolds number, which is ...

Stresses and Strains in a Wrench

This tutorial demonstrates how to set up a simple static structural analysis. The analysis is exemplified on a combination wrench during the application of torque on a bolt. Despite its simplicity, and the fact that very few engineers would run a structural analysis before trying to turn a bolt, the example provides an excellent example of structural analysis in COMSOL Multiphysics.

Laser Heating of a Silicon Wafer - new

A silicon wafer is heated up by a laser that moves radially in and out over time. In addition, the wafer itself is rotated on its stage. The incident heat flux from the laser is modeled as a spatially distributed heat source on the surface. The transient thermal response of the wafer is shown. The peak, average, and minimum temperature during the heating process is computed, as well as the ...

Transport and Adsorption

This model demonstrates how to model phenomena defined in different dimensions in a fully coupled manner using COMSOL Multiphysics. Whereas in most cases the reaction rate expression is defined as a function of the concentrations of the reactants and products, in adsorption reactions it is also necessary to model the surface concentrations of the active sites or surface complex. This implies ...

Micromixer - cluster and batch versions - new

This example studies a laminar static micromixer with two parallel sets of split-reshape-recombine mixing elements. The mixer works through lamination of the streams without any moving parts and the mixing is obtained through diffusion. The purpose of this model is to demonstrate how to access the cluster computing functionality in COMSOL from COMSOL Desktop and use it to submit a batch job to a ...

Laser Heating - A Self Guided Tutorial

This tutorial shows how to model transient heat conduction in a glass slab heated by a laser beam. The tutorial emphasizes on the use of functions to model the laser power as a body heat source. Several key design variables have been parameterized. Suggestions on meshing and solver settings are provided. Three different modes of operation are investigated. - Stationary laser emitting ...

Filling of a Capillary Channel: Level Set and Phase Field Models

This example studies a narrow vertical cylinder placed on top of a reservoir filled with water. Because of wall adhesion and surface tension at the air/water interface, water rises through the channel. Surface tension and wall adhesive forces are often used to transport fluid through microchannels in MEMS devices or to measure, transport and position small amounts of fluid using micropipettes. ...

Sloshing Tank

Transport of large quantities of fluid can happen in unstable environments. A perfect example is an oil tanker on the high seas. This model uses ALE for an incompressible Navier-Stokes problem with a free surface. This models the fluid with its original mesh, but allows the mesh to deform according to the fluid’s ‘deformation’. This requires that the position of the mesh and its nodes ...

Terminal Falling Velocity of a Sand Grain

The first stop for polluted water entering a water work is normally a large tank, where large particles are left to settle. Generally, gravity settling is an economical method of separating particles. If the fluid in the tank is moving at a controlled low velocity, the particles can be sorted in separate containers according to the time it takes for them reach the bottom. This model simulates ...

Marangoni Convection

Marangoni convection occurs when the surface tension of an interface (generally liquid-air) depends on the concentration of a species or on the temperature distribution. In the case of temperature dependence, the Marangoni effect is also called thermo-capillary convection. The Marangoni effect is of primary importance in the fields of welding, crystal growth and electron beam melting of metals. ...
