Stress Analysis of an Elliptic Membrane

Model ID: 14377


This is a benchmark model for a plane stress problem. The accuracy of the computed stress concentration is evaluated, and a mesh convergence study is performed for different element types.

This model was built using the following:

Structural Mechanics Module
