Free Tetrahedral Meshing of a Piston Geometry

Model ID: 14439


This is a tutorial model that demonstrates how to use mesh parameters such as

  • Minimum element size
  • Resolution of curvature
  • Resolution of narrow regions
  • Maximum element growth rate
The instructions also detail how to access the mesh statistics and how to create a mesh plot.

This model was built using the following:

COMSOL Multiphysics
  • models.mph.piston_mesh.pdf *
  • piston_mesh.mph *
  • piston_quarter.mphbin *
